23000-013000 Marine + Industrial

CLAMP, 13

23000-013000 — Affiliate Parts Search

AmazoneBayAliExpress

As an Amazon Associate I earn from qualifying purchases. Other links (eBay, AliExpress) are also affiliate links — they help pay for the site, at no extra cost to you. More

Fitted to

Engines, drives and generators whose parts catalogue lists this part. Open any for its exploded parts list.

Engines
3TN75E-G1 24hp3TN75E-G2 24hp3TN82E-G1 33hp3TN82E-G2 33hp4TN82E-G1 38hp4TN82E-G2 38hp3JH2 38hp3JH2-TE 47hp3JH2Z 38hp3JH3CE 40hp3JH3E 40hp3JH3E(EPA) 40hp3JH40 40hp3JH4E 39hp3JH5E 38.5hp3YM20 21hp3YM30 29hp3YM30AE 29hp4JH 44hp4JH-HT 66hp4JH-T 55hp4JH110 110hp4JH2-DTE 88hp4JH2-HTE 75hp4JH2-TE 62hp4JH2-UTE(B) 100hp4JH3-DTE 125hp4JH3-HTE 100hp4JH3-TBE 75hp4JH3-TCE 75hp4JH3-TE 75hp4JH3CE 56hp4JH3CE1 56hp4JH3E 56hp4JH4-HTE 110hp4JH4-TE 75hp4JH45 45hp4JH4AE 55hp4JH4E 55hp4JH57 57hp4JH5E 53.8hp4JH80 80hp4LH-DTE 170hp4LH-STE 230hp4LHA-DTE(P) 200hp4LHA-DTZE(P) 200hp4LHA-HTE(P) 160hp4LHA-HTZE(P) 160hp4LHA-STE(P) 240hp4LHA-STZE(P) 240hp6LP-DTE 250hp6LP-DTZE 250hp6LP-DTZEP1 250hp6LP-STE 300hp6LP-STZE 300hp6LP-STZEP1 300hp

Supersession

Superseded by
Part No.DescriptionCodeApplies
119172-48130 CLIP, HOSE 13 R A=EXXXXX; B=EXXXXX; C=EXXXXX; D=EXXXXX; A=EXXXXX; B=EXXXXX; C=EXXXXX; D=EXXXXX; E=EXXXXX; F=EXXXXX; A=EXXXXX; C=EXXXXX
124766-59050 CLIP, HOSE 12 N D=EXXXXX
23000-019000 CLAMP, 19 N A=E50514; B=EA0421
Replaces (older)
Part No.DescriptionCodeApplies
124722-59050 CLIP, HOSE 9 N A=E/#20238; B=E/#30345; D=E/#10216
23000-016000 CLAMP, 16 N A=*1999.01; C=*1999.01; A=E/#21367; B=E/#21367; A=E/#E13624
No cross-references recorded for this part yet.

Used in 57 places

Every catalog figure this part is placed in, the model(s) it applies to, and its reference/level/quantity.

Model(s)CatalogFigurePageRefLevQty
3TN75E-G1, 3TN75E-G2, 3TN82E-G1, 3TN82E-G2, 4TN82E-G1, 4TN82E-G2 3TN82E Parts Catalog Fig 27. FUEL STRAINER 43 35 1 2
3JH2, 3JH2-TE 3JH2-TE yanmarshop parts.csv Fig 16. COOLING FRESH WATER SYSTEM 1 27 1
3JH2, 3JH2Z 3JH2 Parts Catalog Fig 22. FUEL PIPE 26 32 1 6
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog Fig 29. FUEL PIPE & FUEL STRAINER 33 17-2 ▲ 1 7
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog (2) Fig 29. FUEL PIPE & FUEL STRAINER 37 17-2 ▲ 1 7
3JH40 3JH40 Parts Catalog Fig 31. FUEL FILTER 35 17 1 4
3JH40 3JH40 Parts Catalog Fig 35. FUEL PIPE 39 6 1 2
3JH4E 3JH4E Parts Catalog Fig 30. FUEL PIPE & FUEL STRAINER 36 11 1 5
3JH4E 3JH4E Parts Catalog Fig 30. FUEL PIPE & FUEL STRAINER 36 17 1 2
3JH5E 3JH5E Parts Catalog Fig 25. FUEL FEED PUMP 29 6 1 2
3JH5E 3JH5E Parts Catalog Fig 28. FUEL PIPE & FUEL STRAINER 32 11 1 9
3JH5E 3JH5E Parts Catalog Fig 29. OIL/WATER SEPARATER 33 16 1 2
3YM20 3YM20 Parts Catalog Fig 23. FUEL INJECTION VALVE & FUEL INJECTION PIPE 32 30-1 ▲ 1 2
3YM20 3YM20 Parts Catalog Fig 48. (24A)WATER SEPARATOR 34 19 1 2
3YM30, 3YM30AE 3YM30AE Parts Catalog Fig 21. FUEL INJECTION VALVE & FUEL INJECTION PIPE 26 30 1 2
4JH-HT 4JH 4JH-T 4JH-HT Parts Catalog Fig 12. SUCTION MANIFOLD 18 15 1 2
4JH, 4JH-HT, 4JH-T 4JH 4JH-T 4JH-HT Parts Catalog Fig 34. FUEL LINE 47 61 1 8
4JH2-TE 4JH2 Parts Catalog Fig 10. SUCTION MANIFOLD(4JH2-TE) 19 16 1 2
4JH2-DTE, 4JH2-HTE 4JH2 Parts Catalog Fig 11. SUCTION MANIFOLD(4JH2-HTE,DTE,UTE) 20 17 1 2
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B) 4JH2 Parts Catalog Fig 28. COOLING FRESH WATER PIPE 39 11 1 2
4JH2-TE 4JH2E Parts Catalog Fig 10. SUCTION MANIFOLD(4JH2-TE) 19 16 1 2
4JH2-DTE, 4JH2-HTE 4JH2E Parts Catalog Fig 11. SUCTION MANIFOLD(4JH2HT,DT,UTE 20 17 1 2
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B) 4JH2E Parts Catalog Fig 28. COOLING FRESH WATER PIPE 39 11 1 2
4JH3-DTE 4JH3-HTE-DTE Parts Catalog Fig 10. SUCTION MANIFOLD 11 31 1 2
4JH3-DTE, 4JH3-HTE 4JH3-HTE-DTE Parts Catalog Fig 24. COOLING FRESH WATER PIPE 26 8 1 4
4JH3-DTE, 4JH3-HTE 4JH3-HTE-DTE Parts Catalog Fig 31. FUEL PIPE 33 17-1 ▲ 1 9
4JH3-TBE, 4JH3-TCE, 4JH3-TE 4JH3E Parts Catalog Fig 31. COOLING FRESH WATER PIPE 35 11 1 2
4JH3CE, 4JH3CE1, 4JH3E 4JH3E Parts Catalog Fig 41. FUEL PIPE(4JH3E) 48 17-2 ▲ 1 7
4JH3-TBE, 4JH3-TCE, 4JH3-TE 4JH3E Parts Catalog Fig 42. FUEL PIPE(4JH3-TE) 50 17-1 ▲ 1 9
4JH4-HTE, 4JH4-TE 4JH4-TE-HTE Parts Catalog Fig 9. SUCTION MANIFOLD 13 24 1 2
4JH4-HTE, 4JH4-TE 4JH4-TE-HTE Parts Catalog Fig 24. COOLING FRESH WATER PIPE 29 8 1 4
4JH4-HTE, 4JH4-TE 4JH4-TE-HTE Parts Catalog Fig 31. FUEL PIPE & FUEL STRAINER 36 36 1 2
4JH45, 4JH57 4JH45-4JH57 Parts Catalog Fig 32. FUEL FILTER 40 16 1 4
4JH45, 4JH57 4JH45-4JH57 Parts Catalog Fig 34. FUEL PIPE 43 9 1 2
4JH4AE 4JH4AE Parts Catalog Fig 26. FUEL FEED PUMP 31 6 1 2
4JH4AE 4JH4AE Parts Catalog Fig 29. FUEL PIPE & FUEL STRAINER 34 11 1 9
4JH4AE 4JH4AE Parts Catalog Fig 30. OIL/WATER SEPARATER 35 16 1 2
4JH4E 4JH4E Parts Catalog Fig 31. FUEL PIPE & FUEL STRAINER 37 11 1 7
4JH4E 4JH4E Parts Catalog Fig 31. FUEL PIPE & FUEL STRAINER 37 17 1 2
4JH5E 4JH5E Parts Catalog Fig 25. FUEL FEED PUMP 29 6 1 2
4JH5E 4JH5E Parts Catalog Fig 28. FUEL PIPE & FUEL STRAINER 32 11 1 9
4JH5E 4JH5E Parts Catalog Fig 29. OIL/WATER SEPARATER 33 16 1 2
4JH110, 4JH80 4JH80-4JH110 Parts Catalog Fig 37. COOLING PIPE(FRESH WATER) 44 8 1 4
4JH110, 4JH80 4JH80-4JH110 Parts Catalog Fig 41. FUEL FILTER 48 16 1 4
4JH110, 4JH80 4JH80-4JH110 Parts Catalog Fig 43. FUEL PIPE 51 9 1 2
4LH-STE 4LH Parts Catalog Fig 26. AIR DUCT(4LH-STE) 39 20 1 2
4LH-DTE 4LH Parts Catalog Fig 60. FUEL RETURN PIPE(4LH-DTE) 83 14 1 2
4LH-STE 4LH Parts Catalog Fig 61. FUEL RETURN PIPE(4LH-STE) 85 7 1 9
4LH-STE 4LH Parts Catalog Fig 61. FUEL RETURN PIPE(4LH-STE) 85 7-1 ▲ 1 8
4LH-STE 4LH Parts Catalog Fig 61. FUEL RETURN PIPE(4LH-STE) 85 8 1 2
4LHA-DTE(P), 4LHA-DTZE(P), 4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 12. SUCTION MANIFOLD 19 12 1 2
4LHA-DTE(P), 4LHA-STE(P) 4LHA Parts Catalog Fig 13. EXHAUST MANIFOLD 20 23 1 4
4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 48. FUEL PIPE(4LHA-ST/DT(Z)E(P)) 64 21 1 2
4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 48. FUEL PIPE(4LHA-ST/DT(Z)E(P)) 64 22 1 2
4LHA-DTE(P), 4LHA-DTZE(P), 4LHA-HTE(P), 4LHA-HTZE(P), 4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 63. SENSOR MOUNT 83 11 1 2
6LP-DTE, 6LP-DTZE, 6LP-DTZEP1, 6LP-STE, 6LP-STZE, 6LP-STZEP1 6LP Parts Catalog Fig 13. BOOST CONTROL 20 3 1 2
6LP-DTE, 6LP-STE 6LP Parts Catalog Fig 14. EXHAUST MANIFOLD 21 23 1 2
